Empire Comfort Systems Fireplace Service in Tsawwassen

Empire Comfort Systems makes gas fireplaces, inserts, stoves, and log sets in direct-vent, B-vent, and vent-free versions, many with a choice of standing or intermittent pilot. The first job on a Tsawwassen service call is confirming which combination is in the wall.

Two Empire fireplaces that look identical from the sofa can vent differently, ignite differently, and take different parts. Chimney Sweep Tsawwassen technicians begin each cleaning, inspection, and repair on these units by reading the rating plate and tracing the vent before a burner is touched, because the right service sequence depends on both.

The Empire Comfort Systems Range We Service Across Tsawwassen

Empire Comfort Systems has built gas heating equipment in Belleville, Illinois since a sheet metal shop opened there in 1911, and its hearth range still reflects that gas-first history. The current line includes direct-vent fireplaces, inserts, and freestanding stoves, B-vent fireplaces, the Boulevard linear fireplace in direct-vent and vent-free forms, and vented log sets with ceramic fibre or refractory logs. Much of the hearth range is sold under the American Hearth name. A vent-free line, including the Vail, Loft, and Breckenridge models, exists for markets that allow it; vent-free appliances are restricted or prohibited in many areas, so most Empire Comfort Systems units we see in Tsawwassen are vented.

Each category asks for a different visit. A vented log set sits inside a masonry fireplace, so its service includes the flue and the damper. A B-vent fireplace draws room air for combustion and needs a draft check. A direct-vent model is sealed, and its glass gasket is part of the safety system.

Standing Pilot or Intermittent Pilot: Sorting Out Ignition on an Empire Unit

An Empire direct-vent fireplace was sold with either a standing pilot and millivolt valve or an intermittent pilot ignition system, and the two need different diagnostic steps. On the millivolt version, a thermocouple holds the pilot gas open and a thermopile generates the small current that opens the main valve when the wall switch or remote closes the circuit. A thermopile that reads low under load gives you a pilot that burns fine while the main burner refuses to come on, or drops out after a few minutes.

The intermittent pilot version sparks the pilot fresh each time you call for heat, proves the flame with a sensing rod, then opens the burner. Its complaints sound different: clicking with no flame, or a pilot that lights and shuts down before the burner joins it. We test the module, the wiring to the valve, and the sensing rod in that order. Conversion kits between natural gas and propane are sold by ignition type, so the fuel and the ignition on the plate both have to match before a kit or valve is ordered.

On an Empire gas fireplace, the ignition type printed on the rating plate decides whether the thermopile or the control module gets tested first.

Common Calls From Owners of These Units

The calls we take on these fireplaces split along the same lines as the range: pilot and valve issues on millivolt units, module and sensor faults on intermittent pilot units, and glass, log, and venting complaints on all of them. Here is what usually sits behind each one around Tsawwassen.

• Main burner ignores the wall switch - on a millivolt unit, a thermopile output too weak under load, or a switch wire corroded at the valve terminals.

• Clicking but no flame - an intermittent pilot unit with tired batteries, a cracked igniter electrode, or a pilot hood blocked with dust after a summer idle.

• Blue, noisy, lifting flames - a log set shifted off its locating pins, or ember material packed over burner ports the manual says to leave clear.

• Soot on the glass or the logs - logs placed outside the pattern in the manual, or a vent-free unit burning dusty room air.

• Start-up odour that does not fade - on a vent-free unit, dust burning off the burner is normal for a minute; if it lingers, shut the unit off and call.

Reading the Rating Plate on a Empire Comfort Systems Fireplace

The rating plate on a direct-vent fireplace of this make sits inside the control compartment behind the lower front or louvers, and vented log sets carry it on the burner pan or the valve bracket. It lists the model number, the serial number, the fuel the unit was set up for, and the ignition type, which is the detail that matters most to us. The model name tells us the family: a Boulevard linear, a Keystone, a Renegade, or one of the Vail, Loft, or Breckenridge vent-free units.

Photograph that plate before you call, along with the front of the fireplace and the vent termination on the outside wall if you can find it. Those pictures let our technician arrive with the correct pilot assembly, thermopile, or glass gasket on the truck instead of making a second trip.

Venting Differences Between Direct-Vent, B-Vent, and Vented Log Sets

Direct-vent, B-vent, and vented log set units from this maker each send combustion gases along a different path, and each path gets its own inspection. A direct-vent model vents through a sealed coaxial pipe, top or rear, and its weak points are the glass gasket and the outside termination, which we check for a nest, snow crust, or a loose cap. A B-vent fireplace takes combustion air from the room and vents up a double-wall pipe to the roof. A range hood or bathroom fan running at the same time can pull that draft backward, so we test with the house fans on.

A vented log set is the one that shares a masonry chimney. Its damper must be held open with a damper clamp, and the flue above it still collects soot and any creosote left from wood burning, so a sweep is part of the service. A working carbon monoxide alarm on the same floor matters most with these open units and with B-vent models. If it sounds, or you notice a headache or a sour smell while the fire runs, turn the gas off at the valve, open a window, and have us out before you relight.

A vented gas log set shares the masonry chimney it sits in, so its service includes a damper clamp check and a flue inspection.

Arranging a Service Visit in Tsawwassen

The first visit on an Empire unit is a test burn with the front removed, a millivolt or module reading, and a check of log placement and the vent path. With the pilot assembly cleaned each year and the logs kept on their locating pins, the burner and valve on these fireplaces stay in service for many heating seasons. Chimney Sweep Tsawwassen technicians are licensed and insured for gas appliance work, and parts are sourced by the model and serial number on your plate.

Empire Comfort Systems owners throughout Tsawwassen can call (778) 601-9107 to set a time. You can also contact us with your rating plate photo and a note on whether the unit is natural gas or propane, and Chimney Sweep Tsawwassen will confirm the likely parts before the technician arrives.
